At Rockeypad, our silicone Keyboards are utilized across a diverse range of devices, each with unique requirements such as tactile feel, wear resistance, actuation force, lifespan, and compression set. While silicone material inherently possesses waterproof properties, achieving a truly waterproof silicone Keyboard necessitates a thoughtful design that integrates seamlessly with the plastic assembly housing. This blog explores the critical elements of designing waterproof silicone Keyboards, sharing insights and best practices based on our extensive experience as a leading manufacturer in this space.
The Importance of Waterproof Design
Electronic devices are vulnerable to damage when liquids such as water or oil invade their internal components. If moisture penetrates the circuit board, it can lead to significant malfunctions, necessitating extensive repairs or, in many cases, complete replacement. Hence, implementing a robust waterproof design for silicone rubber Keyboards is essential not only for functionality but also for longevity and reliability.
Key Considerations for Waterproof Silicone Keyboard Design
Creating a waterproof silicone Keyboard involves several key design strategies:
- Avoiding Positioning Holes: Traditional designs often include holes for positioning or fixing silicone buttons. However, these holes can serve as entry points for water, compromising the integrity of the circuit board. To mitigate this risk, our design philosophy emphasizes eliminating positioning holes in waterproof Keyboards, ensuring a smooth, uninterrupted surface that reduces the likelihood of liquid infiltration.
- Innovative Edge Structure: To enhance the waterproof capabilities of silicone Keyboards, we design an elevated waterproof wall that surrounds the Keyboard. This structure acts as a barrier, preventing water from reaching sensitive electronic components. Additionally, we incorporate a fixed positioning groove, often in a semicircular shape, that aligns with the chassis and circuit board while maintaining a safe distance from critical areas. This thoughtful design ensures that even if water droplets land on the Keyboard, they are diverted away from the interior components.
- Sealing with Resin or Glue: Although gaps between the silicone Keyboardand the assembly housing can exist, applying a resin or glue can significantly improve the sealing effect. While this method can enhance waterproofing, it requires careful application to avoid excess material that could detract from the Keyboard’s appearance. Therefore, we recommend designing the Keyboard in such a way that waterproofing is inherently built into the structure.
Case Study
One of our recent projects involved a French client seeking a custom UV-resistant rubber Keyboard for a motorcycle remote controller. The requirements specified that the Keyboard needed to incorporate two push buttons and two LEDs while ensuring a splashproof design suitable for outdoor use.
Custom Silicone Keyboard Specifications
The client’s specifications included:
– A translucent silicone base
– A black spray coating for the key tops
– White symbols printed via silk screening
Despite the straightforward requirements, the most critical challenge was ensuring the Keyboard’s waterproof integrity. Upon reviewing the original design, our engineers noted a lack of structural support beneath the buttons and an absence of waterproof grooves. This design flaw posed a significant risk; if pressure was applied to the buttons, the entire Keyboard could become misaligned, creating gaps that would allow water ingress.
Engineering Solutions
To address these concerns, our engineering team proposed a comprehensive redesign of the silicone Keyboard, transforming it into a fully sealed structure that would securely encase the electronic components. The enhanced design featured thicker walls, ensuring that the Keyboard maintained a waterproof seal while delivering an aesthetically pleasing appearance.
Final Manufacturing Process
To meet the customer’s aesthetic and functional requirements, the final manufacturing process for the custom remote control silicone Keyboard involved several key steps:
- UV-Resistant Translucent Silicone Base: This durable material offers both protection against UV exposure and a visually appealing finish.
- Spraying Black Coating: A black spray coating was applied to the button tops, enhancing visibility and functionality.
- Spraying White Coating: This step involved adding white symbols to ensure clear communication for the end user.
- Laser Cutting and Etching: Precise laser cutting was used to create a translucent triangular window for the LEDs, along with etching white symbols, legends, and characters for clarity.
- Application of PU Protective Coating: A final spray of polyurethane provided additional protection against environmental factors.
Production Considerations
To deliver a high-quality product that met all specifications, we also developed a specialized positioning tool for the spray application. This tool ensured that the black coating was applied uniformly around the edges of the rubber Keyboard. However, this method required additional steps in the production process, resulting in increased labor costs and longer lead times.
Rockeypad’s Competitive Advantages
As a leading manufacturer of waterproof silicone Keyboards, Rockeypad prides itself on delivering customized solutions tailored to our clients’ needs. Our advantages include:
– Expertise in Material Science: We leverage our deep understanding of silicone materials to optimize performance and durability.
– Innovative Design Solutions: Our engineering team employs cutting-edge design practices to ensure that our products not only meet but exceed industry standards.
– Commitment to Quality: We adhere to stringent quality control measures throughout the manufacturing process, ensuring that each Keyboard is reliable and functional.
– Customization Flexibility: We offer extensive customization options to meet specific client requirements, whether for aesthetic appeal or functional performance.
Conclusion
Designing waterproof silicone Keyboards is a multifaceted process that requires careful consideration of material properties, structural integrity, and environmental exposure. By integrating innovative design strategies and employing advanced manufacturing techniques, Rockeypad ensures that our silicone Keyboards not only meet but exceed client expectations for performance and reliability. Whether for outdoor use or intricate electronic devices, our commitment to quality and innovation positions us as the preferred partner for your silicone Keyboard needs. If you’re looking for custom solutions that deliver exceptional performance and durability, contact us today to learn how we can help!
